RGB+W 4-ZONE Controller - Receiver 24A
Description
Wireless lighting control system LED RGBW about the current carrying capacity up to 24A. For proper operation of the system is required pilot available HERE. Remote control, you can set different modes of light - function to change the color and intensity of light. By controlling your finger on the touch panel we get any light color. A separate channel allows independent control of a stream of white color.
The controller has many additional features m.in .: - Its own sequence can be programmed to change colors individually to each of the receivers, - On / off individual zones - Change the speed preset programs (flashing, and a smooth transition of colors) - Change brightness tapes / RGB LED luminaires When you connect a remote control to any number of receivers, we can control the light intensity up to four independent zones LED. Pairing the receiver of the remote control is illustrated in our Video section is available HERE.
An assignment circuit to one zone on the remote control: - Turn off the power to the receiver in the first zone to be programmed - Restart the disconnected receiver lighting selected zone and within 3 seconds, press the "I" (ON) on the remote control are chosen by us - If connecting zones will be successful, lights will blink 3 times
Technical data
The output | 12 - 24V DC |
Input voltage range | - |
The method of regulating | remote |
Predefined colors | - |
Dimmable | yes |
Number of preset programs | - |
Range | - |
Weight | - |
Pilot dimensions | - |
Working temperature | - |
Signal connector ( output ) | socket terminal |
Controller dimensions | 85 x 45 x 23 [mm ] |
Power connection | socket terminal |
Speed control | no |
Way communication with remote control | radio |
Max . current carrying capacity | 24A (4 x 6A) |
Number of colors predefined | - |
Additional information | - |
